IS-05

  • Player who is looking for higher trajectory.
  • Lady golfer who has higher swing speed than avarage lady golfer.
  • Player who would like to gain distance easily by using slightly heavier shaft.
  • Player who is aiming for straighter shot.

Carry distance, easy-to-hit,easy-to-address The best BERES Iron ever.

  • Higher carry performance
  • With the New face structure, the stress on impact is concentrated and the energy is transferred to the ball without loss, providing a longer carry distance.
  • The face's repulsion area is expanded by 25% (compared to the previous model).
  • The face area is expanded by removing the welds from the face. It enables higher ball repulsion performance of the entire surface of the face.
  • The larger head size enhances forgiveness.
  • Both the face height and width are expanded by 1 mm. The only 1-mm expansion provides comfort to the golfers.

Structural drawings

IS-05 Structural drawings

IS-05 Structural drawings

New face structure(#4-8)

The face with the New face structure provides a larger face area, expanding the repulsion area by approximately 25% (Compared to IS-03). This increases the carry performance and reduces loss of distance caused by mishits.

IS-05
IS-05
IS-05
IS-05

Head size

IS-05 has a larger head size with more forgiveness.

IS-03よりヘッド長さを1mm長く

The head length is 1 mm longer than that of the IS-03.


The height of the toe part is 1 mm higher than that of the IS-03.

IS-03からトゥ・ヒール部分の高さを1mm高く

The head shape looks more upright with the higher toe side, providing visual confidence to players at address.

Compared to the previous model.

従来モデル(IS-03)比較

Page Top

SPEC

Head material/Manufacturing process Mild Steel/Forged(body)・ Maraging stainless steel(face)
Head plating Double-layer plating / Satin finish + Painted finish
Shaft ARMRQ∞ 48, ARMRQ∞ 53, ARMRQ∞ 44
# (No.) 4 5 6 7 8 9 10 11 AW SW
Length(inches) 38.5 38.0 37.5 37.0 36.5 36.0 35.5 35.0 35.0 35.0
Loft (deg.) 19.5 22.5 25.5 28.5 32.5 36.5 41.5 46.5 51.5 56.0
Lie angle (deg.) 60.5 61.0 61.5 62.0 62.5 63.0 63.0 63.0 63.0 64.0
Face progression(mm) 2.45 2.75 3.05 3.25 3.25 3.25 3.25 3.25 3.25 4.25
Distance to Center of Gravity(mm) 36.5 36.5 37.0 37.0 36.5 36.5 36.5 36.5 36.5 37.0
Height to Center of Gravity(mm) 18.5 19.0 19.5 19.5 20.0 20.0 20.5 21.5 22.0 23.0
Depth to Center of Gravity(mm) 6.5 6.5 6.5 6.0 5.5 4.5 4.0 4.0 3.0 2.5
Gravity Angle(deg.) - 13.0 - - - - - - - -
Swing weight・
Gross weight (g)
ARMRQ∞ 48 R C8・352 C8・358 C8・365 C8・371 C8・377 C8・384 C8・390 C8・396 C8・396 C9・398
SR C9・355 C9・361 C9・368 C9・374 C9・380 C9・387 C9・393 C9・399 C9・399 D0・401
S C9・356 C9・362 C9・369 C9・375 C9・381 C9・388 C9・394 C9・400 C9・400 D0・402
ARMRQ∞ 53 R C9・358 C9・364 C9・370 C9・376 C9・383 C9・390 C9・396 C9・402 C9・402 D0・405
S D0・362 D0・368 D0・374 D0・380 D0・387 D0・394 D0・400 D0・406 D0・406 D1・409
ARMRQ∞ 44 R C8・349 C8・355 C8・361 C8・367 C8・373 C8・380 C8・386 C8・392 C8・392 C9・395
Data refers to the 2S grade
Made in Japan
2S 3S 4S

Page Top

SHAFT

ARMRQ∞ 48(Standard feature)

Material Carbon+eight-axisUD
Kick-point Low-Mid
Flex R,SR,S
Butt diameter (mm) #7 15.3
Tip diameter (mm) 9.3
# (No.) 4 5 6 7 8 9 10 11 AW SW
Gross weight (g) R 52.5 53.0 52.5 53.0 52.5 53.0 52.5 52.0 52.0 52.0
SR 54.0 54.5 54.0 54.5 54.0 54.5 54.0 53.5 53.5 53.5
S 55.5 56.0 55.5 56.0 55.5 56.0 55.5 55.0 55.0 55.0
Torque (deg.) R 3.31 3.24 3.17 3.10 3.03 2.96 2.89 2.82 2.82 2.82
SR 3.26 3.19 3.12 3.05 2.98 2.91 2.84 2.77 2.77 2.77
S 3.21 3.14 3.07 3.00 2.93 2.86 2.79 2.72 2.72 2.72
Frequency (cpm) R 259 267 275 283 291 299 307 315 315 315
SR 267 275 283 291 299 307 315 323 323 323
S 275 283 291 299 307 315 323 331 331 331
Data refers to the 2S grade/shaft only

ARMRQ∞ 53

Material Carbon+eight-axisUD
Kick-point Mid
Flex R,S
Butt diameter (mm) #7 15.4
Tip diameter (mm) 9.3
# (No.) 4 5 6 7 8 9 10 11 AW SW
Gross weight (g) R 57.0 57.5 57.0 57.5 57.0 57.5 57.0 56.5 56.5 56.5
S 60.0 60.5 60.0 60.5 60.0 60.5 60.0 59.5 59.5 59.5
Torque (deg.) R 3.11 3.04 2.97 2.90 2.83 2.76 2.69 2.62 2.62 2.62
S 3.01 2.94 2.87 2.80 2.73 2.66 2.59 2.52 2.52 2.52
Frequency (cpm) R 264 272 280 288 296 304 312 320 320 320
S 280 288 296 304 312 320 328 336 336 336
Data refers to the 2S grade/shaft only

ARMRQ∞ 44

Material Carbon+eight-axisUD
Kick-point Low
Flex R
Butt diameter (mm) 14.5
Tip diameter (mm) 9.3
# (No.) 4 5 6 7 8 9 10 11 AW SW
Gross weight (g) 47.5 48.0 47.5 48.0 47.5 48.0 47.5 47.0 47.0 47.0
Torque (deg.) 3.75 3.68 3.61 3.54 3.47 3.40 3.33 3.26 3.26 3.26
Frequency (cpm) 244 251 258 265 272 279 286 293 293 293
Data refers to the 2S grade/shaft only

Page Top

GRIP

Name BERES RubberⅢ
Material Rubber
Gross weight (g) 47
Size 60
Data refers to the 2S grade
