IE-05

  • Player who would like to swing exhilaratingly.
  • Player who is aiming for straighter shot.
  • Player who would like to reduce slice for longer distance.
  • Player who would like to gain distance with flexibility of the club(Shaft).

The unique irons made with the suitable designed parts

  • New idea, weight distribution to sole/heel
  • Irons having the head mechanism with the greatest grip for target golfers, which transfers maximum energy to the ball.
  • New face strucuture is adopted (#5-#8)
  • The new face strucuture expands the repulsion area with a larger head is best suited for the target golfers who cannot hit down on the ball.
  • Optimum center-of-gravity provided by new sole thickness design
  • The new sole design with a thicker bottom and leading edge provides an extreme lower and deeper center of gravity. Ball is easier to lift and grip.

Structural drawings

IS-05 Structural drawings

IS-05 Structural drawings

Weight distribution


Weight distribution to heel

By redistributing more weight to the heel and moving the center of gravity Inward, Honma have made it easier to grip the ball which leads to higher ball speeds.

The New face strucuture (#5-#8).

The New face strucuture is expanded to the lower portion of the face. The number of mishits by variation of impact is reduced. The thicker sole of the back provides the lower/deeper center of gravity. This design allows you to easily hit shots with high trajectory.


IE-05
IE-05
New sole thickness design


New sole thickness design

The new sole design with a thicker bottom and leading edge provides an extreme lower and deeper center of gravity. Ball is easier to lift and grip.

Larger face size

The face of the toe/heel is 1 mm higher than IE-03, providing the expanded repulsion area, comfort and easy to address shape.

IE-05
IE-05
The face of the toe/heel is 1 mm higher than IE-03.

Compared to the previous model

Compared to the previous model

Page Top

SPEC

Head material/Manufacturing process SUS630/Casting(body)・ Maraging stainless steel(face)
Head plating Double-layer plating / Satin finish + Painted finish
Shaft ARMRQ∞ 44
# (No.) 5 6 7 8 9 10 11 SW
Length(inches) 38.0 37.5 37.0 36.5 36.0 35.5 35.0 35.0
Loft (deg.) 24.0 27.0 30.0 34.0 38.0 43.0 49.0 56.0
Head volume(°) 61.0 61.5 62.0 62.5 63.0 63.0 63.0 63.5
Face progression(mm) 1.75 2.25 2.75 2.75 3.25 3.75 3.75 4.25
Distance to Center of Gravity(mm) 37.5 37.5 37.5 37.5 37.5 37.0 36.0 36.0
Height to Center of Gravity(mm) 20.5 21.0 21.0 22.0 22.5 23.0 22.5 22.5
Depth to Center of Gravity(mm) 5.0 5.0 5.0 4.5 4.0 3.5 3.0 2.5
Gravity Angle(deg.) 13.5 - - - - - - -
Swing weight・
Gross weight (g)
ARMRQ∞ 44 R C6・336 C6・342 C6・348 C6・354 C6・360 C6・366 C6・372 C7・374
Data refers to the 2S grade
Made in Japan
2S 3S 4S
Please check difference of shaft grade

Page Top

SHAFT

Please click here for details of shaft.

ARMRQ∞ 44

Material Carbon+eight-axisUD
Kick-point Low
Flex R
Butt diameter (mm) 14.5
Tip diameter (mm) 9.3
# (No.) 5 6 7 8 9 10 11 SW
Gross weight (g) 48.0 47.5 48.0 47.5 48.0 47.5 47.0 47.0
Torque (deg.) 3.68 3.61 3.54 3.47 3.40 3.33 3.26 3.26
Frequency (cpm) 251 258 265 272 279 286 293 293
Data refers to the 2S grade/shaft only

Page Top

GRIP

Name BERES RubberⅢ
Material Rubber
Gross weight (g) 36.5
Size 60
Data refers to the 2S grade
