S-05

  • Player who is looking for higher trajectory with Low kickpoint shaft.
  • Player who would like to reduce slice for longer distance in avarage.
  • Player who is aiming for straighter shot.
  • Lady golfer who has higher swing speed than avarage lady golfer.
  • Player who is looking for a forgiving club.

All parts, technologies, and developments are for longer carry distances.

  • The face's deflection strongly supported by the new crown and sole design
  • The resilience of the crown and sole by deflection on impact supports the repulsion of the face.
  • The impact from a hit is transmitted effectively to the crown & sole by the face design.
  • The three new internal ribs extended from the face exert the never-before-seen interlocking effect between parts, resulting in high resilience and efficiency.
  • The face designed to give the highest performance
  • The Ti-6-4 high-dense forging method allows us to have the partially different thickness design based on thorough calculation, providing the most efficient face deflection for players.

Structural drawings

S-05 Driver
S-05 Driver
■Crown
"Ti-3-2.5 Forge-cast Crown Honeycomb + Rib Mechanism"
■Inner weight
Optimum spin performance and high trajectory provided by the ideal weight positioning.
■Face
"Ti-6-4 High-dense Forging Method"
■Rib
■Weight(SUS 5g)
Through internal weighting Honma have lowered the center of gravity.
■Body section
G4Ti - high strength and formability is implemented.

The face's deflection strongly supported by the new crown and sole design

S-05ドライバー:クラウンパーツ,ソールパーツ

The impact caused by hitting balls is converted into effective deflection of the crown, which propagates the deflection and resilience to the surface of the face, creating the longest carry distance and ball speed in the series.

"Ti-3-2.5 Forge-cast Crown Honeycomb + Rib Mechanism"
Sole: G4 Ti Forge-cast Groove Rib Design.

Face"Ti-6-4 High-dense Forging Method"

The three internal ribs extend from the thick part of the face (center) efficiently broadcast the impact caused by hitting balls to the crown/sole.
The resilience of crown/sole deflection during impact works in harmony with the repulsion of the face surface, providing powerful trajectories.

S-05
Rib

The total design of head and shaft.

∞ shaft that satisfies the high trajectories, low spin, and easily catches the ball, ARMRQ∞.

Ti-5N」 「Ti-5N」
  • The hitting angle is stable even with low spin because of the shaft design.
  • The shaft is specially designed for the S-05 with a high launch angle and head speed ensures a longer carry distance.
  • The stiffness distribution adds the stable direction of the hit to the excellent grip.
  • The combination of the head with the excellent grip and the shaft that allows you to hit easily from the inside while providing stable direction and carry performance.

Please click here for details of shaft.

Page Top

SPEC

Head material/Manufacturing process Crown : 3AL-2.5V1Titanium
Sole : G4Titanium/Forged
Face material/ Manufacturing process 6-4Titanium/ Forged
Shaft ARMRQ∞ 48, ARMRQ∞ 53, ARMRQ∞ 44
Length(inches) 46.25
Loft (deg.) 9.5 10.5
Head volume(cm3) 460
Lie angle (deg.) 60.0
Distance to Center of Gravity(mm) 42.0 42.5
Height to Center of Gravity(mm) 35.0 35.5
Effective hitting area(mm) 23.5 23.0
Depth to Center of Gravity(mm) 38.0 39.0
Gravity Angle(deg.) 22.5 23.0
Swing weight・Gross weight(g) ARMRQ∞ 48 R D1・281
SR D2・284
S D2・285
ARMRQ∞ 53 R D1・290
S D2・294
ARMRQ∞ 44 R D1・277
Data refers to the 2S grade
Made in Japan
2S 3S 4S
Please check difference of shaft grade

Page Top

SHAFT

Please click here for details of shaft.

ARMRQ∞ 48(Standard feature)

Material Carbon+eight-axisUD
Kick-point Low-Mid
Flex R,SR,S
Butt diameter (mm) R 15.3
SR 15.3
S 15.4
Tip diameter (mm) 8.6
Gross weight (g) R 48.5
SR 50.0
S 51.5
Torque (deg.) R 4.65
SR 4.60
S 4.55
Frequency (cpm) R 237
SR 245
S 253
Data refers to the 2S grade/1W shaft only

ARMRQ∞ 53

Material Carbon+eight-axisUD
Kick-point Mid
Flex R,S
Butt diameter (mm) R 15.4
S 15.5
Tip diameter (mm) 8.6
Gross weight (g) R 53.5
S 56.5
Torque (deg.) R 4.15
S 4.05
Frequency (cpm) R 251
S 267
Data refers to the 2S grade/1W shaft only

ARMRQ∞ 44

Material Carbon+eight-axisUD
Kick-point Low
Flex R
Butt diameter (mm) 15.1
Tip diameter (mm) 8.6
Gross weight (g) 44.5
Torque (deg.) 5.75
Frequency (cpm) 206
Data refers to the 2S grade/1W shaft only

Page Top

GRIP

Name BERES RubberⅢ
Material Rubber
Shaft ARMRQ∞ 48, ARMRQ∞ 44 ARMRQ∞ 53
Gross weight (g) 38 43
Size 60 60
Data refers to the 2S grade/1W shaft only
